DG300-1500SP DC GENERATOR
BDT 47,808/-
Product Details
Brand: MCP
Model: DG300-1500SP
Country Of Origin: China
Main Advantages
Separate excitation for precise control
Stable 220VDC output
Powerful 250W output
Durable and heavy-duty construction
Easy wiring with labeled terminals
Reliable 1500rpm performance
Suitable for education and research
| Type: | DC Generator |
| Excitation Voltage: | 0~220VDC |
| Excitation Current: | 0.14A |
| Max. Output Voltage: | 220VDC |
| Max. Output Power: | 250W |
| Max. Rotate Speed: | 1500rpm |
| Shaft Height: | 75mm |
| Dimensions: | 280 x 180 (200) x 150 mm |
| Weight: | 13.5kg |
The MCP DG300-1500SP DC Generator is a powerful, industrial-grade generator designed for reliable DC power generation with precise control. Ideal for industrial, commercial, and educational applications, it features separate excitation windings, allowing independent control of the field and armature for accurate voltage regulation. The DG300-1500SP operates on an excitation voltage of 0~220VDC with an excitation current of 0.14A, delivering a maximum output voltage of 220VDC and a maximum output power of 250W. It achieves a maximum rotate speed of 1500rpm. The generator features a 75mm shaft height and dimensions of 280 x 180 (200) x 150 mm, weighing 13.5kg, with clearly labeled terminals (T1, T2, and others) for straightforward wiring.
MCP DG300-1500SP DC Generator – 250W, 220VDC, 1500rpm
Generate reliable DC power with precision using the MCP DG300-1500SP, a powerful DC generator designed for controlled voltage output and dependable performance. Ideal for industrial, commercial, and educational applications, this generator combines separate excitation construction with a robust, heavy-duty design.
Key Features & Benefits:
-
Separate Excitation Design: Allows independent control of the field and armature for precise voltage regulation.
-
Stable DC Output: Delivers a maximum output voltage of 220VDC with a maximum output power of 250W.
-
Wide Excitation Range: Operates on 0~220VDC excitation voltage with a low excitation current of 0.14A.
-
Robust & Heavy-Duty Design: Features a 75mm shaft height, dimensions of 280 x 180 (200) x 150 mm, and a weight of 13.5kg for stable industrial performance.
-
Easy Wiring: Equipped with clearly labeled terminals (T1, T2, and others) for straightforward connection.
-
Industrial-Grade Construction: Built to withstand demanding environments in industrial, commercial, and educational settings.
