MT6055 BENCHTOP DIGITAL MULTIMETER
BDT 113,741/-
Product Details
Brand: MCP
Model: MT6055
Country Of Origin: China
Features:
6-1/2 digits display resolution, the highest reading value displayed is 1200000 words.
The basic DC voltage accuracy is up to 0.0035%.
Multi-function DCV, ACV, DCA and ACA, Resistance, capacitance, frequency, on-off, diode test, thermocouple and thermal resistance temperature measurement, relative value (REL_%) maximum, minimum and average value (MAX/MIN/AVG), measurement comparison, function (COMP).
Manual/automatic measurement ADC integral time, input impedance, automatic zero calibration unit of temperature measurement and cold junction compensation
The auto zero function can be enabled during measurement to eliminate the impact of circuit drift.
2-wire or 4-wire measurement is used for resistance measurement and 4-wire measurement can be used to eliminate the impact of lead resistance
Max. sampling rate up to 0.125PLC (400 times per Sec.)
The AC measuring value is RMS value, The AC voltage measurement bandwidth: 20Hz~100kHz, AC current measurement bandwidth: 20Hz~30kHz.
The reference impedance of 1~2400 Ω can be selected for decibel measurement
Measurement comparison function, limit range (upper/lower limit) can be preset.
4 measurement trigger working modes, and the measurement work of the meter is controlled by these modes
Multimeter data recording function
USB, RS232 interface.
| Display: | 6-1/2 digits, 1,200,000 counts |
| DCV Accuracy: | 0.0035%+0.005% |
| ACV Accuracy: | 0.05+0.03 (100Hz~10kHz) |
| DCA Accuracy: | 0.015%+0.005% |
| ACA Accuracy: | 0.1+0.03 (50Hz~100Hz) |
| Resistance Accuracy: | 0.01%+0.001% |
| Capacitance Accuracy: | 1%+0.5% |
| Frequency Accuracy: | 0.01% (40Hz~100kHz) |
| Input Impedance: | 10MΊ, >10GΊ |
| Power Source: | 250VACÂą10%, 50/60Hz |
| Dimensions: | 245Ã220Ã82 mm |
| Weight: | 2kg |
The MCP MT6065 Benchtop Digital Multimeter is a top-tier, high-precision instrument designed for the most demanding laboratory, industrial, and research applications. It features a 6-1/2 digit display with an impressive 1,200,000-count resolution and a basic DC voltage accuracy of up to 0.0035%. This advanced multimeter offers a comprehensive suite of functions, including DCV (100mV~1000V), ACV (100mV~750V) with True RMS and a 20Hz~100kHz bandwidth, DCA (10mA~10A), ACA (10mA~10A) with a 20Hz~30kHz bandwidth, Resistance (100Ω~100MΩ with 2-wire and 4-wire measurement), Capacitance (10nF~10mF), Frequency (3Hz~100kHz), Duty cycle, Diode test, and Count. It also supports thermocouple (K/E/J/R/S/T/B/N) and RTD (PT100/PT1000) temperature measurements. Key features include manual/automatic ADC integral time, auto zero function, relative value (REL_%), Max/Min/Avg, measurement comparison (COMP), selectable reference impedance for decibel measurement (1~2400Ω), 4 trigger working modes, and data recording. The MT6065 offers USB and RS232 interfaces, measures 245 x 220 x 82 mm, and weighs 2kg.
MCP MT6065 Benchtop Digital Multimeter – 6-1/2 Digit, True RMS, USB/RS232, 1,200,000 Counts
Achieve the ultimate in precision measurement with the MCP MT6065, a flagship benchtop digital multimeter designed for advanced laboratory, industrial, and research applications. Ideal for engineers, scientists, and metrologists, this instrument delivers exceptional accuracy, extensive functionality, and comprehensive connectivity.
Key Features & Benefits:
-
Ultra-High Precision & Resolution: 6-1/2 digit display with 1,200,000 counts and basic DCV accuracy up to 0.0035%.
-
Comprehensive Measurement Functions:
-
DC Voltage: 100mV ~ 1000V
-
AC Voltage (True RMS): 100mV ~ 750V (20Hz~100kHz bandwidth)
-
DC Current: 10mA ~ 10A
-
AC Current: 10mA ~ 10A (20Hz~30kHz bandwidth)
-
Resistance: 100Ω ~ 100MΩ (2-wire and 4-wire)
-
Capacitance: 10nF ~ 10mF
-
Frequency: 3Hz ~ 100kHz
-
Duty Cycle: 0.1% ~ 99%
-
Temperature: Thermocouple (K/E/J/R/S/T/B/N) and RTD (PT100/PT1000)
-
Diode & Continuity Test
-
-
Advanced Features: Auto zero function, relative value (REL_%), Max/Min/Avg, measurement comparison (COMP) with preset limits, selectable reference impedance (1~2400Ω) for decibel measurement, and 4 trigger working modes.
-
High-Speed Sampling: Max. sampling rate up to 0.125PLC (400 times per second).
-
Data Recording & Connectivity: Multimeter data recording function with USB and RS232 interfaces.
-
Reliable Power: Operates on 250VAC±10%, 50/60Hz.
