CC1012M Mini Current Generator
BDT 7,018/-
Product Details
Brand: MCP
Model: CC-1012M
Country Of Origin: China
Features
-
Constant current output
-
Continuously adjustable output current
-
High stability 0.01%
-
Open circuit and over voltage protection
-
3½ digit LCD current meter with backlight
-
Compact, light, and safe
| Output current: | 0–10mA |
| Maximum voltage: | 12V |
| Resolution: | 10µA |
| Load regulation: | 0.01% |
| Line regulation: | 0.01% |
| Display: | 3½ digit LCD with backlight |
| Display accuracy: | ±1 digit |
| Input voltage: | 110V or 220VAC ±10%, 50Hz/60Hz |
| Dimensions: | 115(W) × 100(H) × 130(D) mm |
| Weight: | 0.6kg |
A compact, high-stability constant-current source that delivers a precisely adjustable current from 0 to 10 mA (maximum voltage 12 V).
Purpose
To provide a highly stable and accurately controlled current for testing, calibrating, and driving current-sensitive electronic components and circuits.
Where to use it
Electronics laboratories and calibration benches
Sensor and transducer testing
Educational electronics experiments
Precision circuit development and troubleshooting
How to use it
Set the desired current (0–10 mA) using the continuous adjustment control.
Connect the load — the unit maintains the set current with 0.01% stability.
Monitor the actual current on the backlit 3½-digit LCD display.
Built-in open-circuit and over-voltage protection keeps both the device and the circuit safe.
It is designed for applications that need a clean, precise, and reliable low-level constant current in a small, lightweight package.
The Constant Current Power Supply (0–10mA, 12V) is designed for precision electronics testing and research applications. With continuously adjustable current output, high stability at 0.01%, and built‑in protections against open circuit and over voltage, it ensures safe and reliable operation. The compact design, lightweight build, and 3½ digit LCD display with backlight make it ideal for laboratories, universities, and engineers requiring accurate current control in sensitive experiments.
