M10-QD305 SINGLE OUTPUT ADJUSTABLE DC POWER SUPPLY
BDT 19,921/-
Product Details
Brand: MCP
Model: M10-QD305
Country Of Origin: China
Features
- Output ON/OFF control with voltage preset functionality
- Dual independently adjustable DC output channels
- Built-in USB power output (5V / 2A)
- Supports independent, series, and parallel operating modes
- Constant Voltage (CV) and Constant Current (CC) operation
- Low ripple and low noise output for enhanced stability
- Four 3-digit LED displays for simultaneous voltage and current monitoring of both channels
- Designed for up to 16 hours of continuous full-load operation
- Automatic tracking mode for synchronized dual-channel output
- High-precision regulation for reliable laboratory and industrial applications
- Ideal for electronics testing, research, education, maintenance, and product development
| Output Channels | Dual Independent Adjustable DC Outputs |
| Output Voltage | 0 to 30V × 2 Channels |
| Output Current | 0 to 5A × 2 Channels |
| Operating Modes | Independent, Series, Parallel & Tracking |
| Control Modes | Constant Voltage (CV) / Constant Current (CC) |
| USB Output | 5V / 2A |
| Display | Four 3-Digit LED Displays |
| Output Control | Output ON/OFF Function |
| Preset Function | Voltage Preset Available |
| Line Regulation (CV) | ≤ 5 × 10⁻⁴ + 3mV |
| Line Regulation (CC) | ≤ 4 × 10⁻³ + 3mA |
| Load Regulation (CV) | ≤ 5 × 10⁻⁴ + 3mV (Output Current ≤ 10A) |
| Load Regulation (CC) | ≤ 4 × 10⁻³ + 3mA |
| Ripple & Noise (CV) | ≤ 1.5mVrms |
| Ripple & Noise (CC) | ≤ 3mArms |
| Display Accuracy | ± (0.5% Reading + 2 Digits) |
| Input Voltage | 110 to 127VAC ±10%, 60Hz / 220 to 240VAC ±10%, 50Hz |
What is this
This is a compact adjustable DC power supply. It provides an adjustable output voltage from 0 to 15 V with a maximum output current of 1.5 A.
How is it used
Set the required voltage and connect the output to the electronic circuit or device being tested. The output voltage and current can be monitored during operation.
Where is it used
It is mainly used for:
Electronics laboratory work
Testing electronic circuits
Arduino and microcontroller projects
Sensor and control circuit testing
PCB testing and development
Electronic equipment repair
Educational and training applications
Its main purpose is to provide a stable and adjustable low voltage DC supply for powering and testing electronic circuits and small devices.
The T5‑1501 Compact Transparent Box Adjustable DC Power Supply is a lightweight and portable solution designed for laboratories, education, and electronics testing. It delivers an output voltage range of 0 ~ 15V with a stable 1.5A current capacity, making it suitable for small circuit experiments and training applications. Featuring excellent line regulation (10mV), load regulation (200mV), and ripple suppression (30mVrms), it ensures clean and stable performance. The digital display provides accurate readings with ±(0.5% + 2 digits), while the wide input voltage range (85–265VAC) offers flexibility across different regions. Compact at only 300g, the T5‑1501 is ideal for students, engineers, and hobbyists who need a reliable and portable DC power source.
