ON-LINE pH METER
BDT 180,353/-
Product Details
Brand: INSIZE
Model: 0435-HZ11
Country Of Origin: China
Features:
Suitable for water quality monitoring in the fields of chemical industry, oil refining, metallurgy, pharmacy, power station and environmental protection, etc.
Simultaneously measure pH, ORP, temperature.
Automatic slope calculation and temperature compensation.
Automatically recognizes 4.00, 6.86, 9.18 standard solutions.
With power failure data protection.
Tray-mounted or wall-mounted for easy installation and operation.
Upper and lower limit alarms can be set.
Protection level: IP65.
| pH: range | 0.00~14.00pH |
| resolution | 0.01pH |
| accuracy* | ±(0.05pH+1d) |
| ORP: range | -1800mV~+1800mV |
| resolution | 1mV |
| accuracy* | ±(10mV+1d) |
| Temperature: range | -10.0°C~120.0°C |
| resolution | 0.1°C |
| accuracy* | ±(1.0°C+1d) |
| Measurement of water sample temperature | 0°C~60°C |
| Isolated output signal | (4~20)mA DC, maximum load750Ω |
| Output upper and lower limits | pH: (0.00~14.00)pH optional, ORP: (-1800~+1800)mV optional |
| Sample flow rate | (100~120)mL/min |
| Inlet pressure | (7~140)kPa |
| Combination electrode: liquid junction | PTFE double salt bridge |
| reference structure | Ag/AgCl |
| temperature compensation unit | PT1000 |
| housing material | PP |
| outline dimension | Ø30×170mm |
| output signal | analog signal |
| connector | fork blade |
| installation mode | 3/4NPT |
| pressure range | ≤0.6MPa |
| applicable samples | routine or contaminated samples |
| Operating environment | temperature: (-5~50)°C, relative humidity: ≤90% |
| Power supply | AC 220V, 50Hz |
| Hole-opening size | 140×140mm |
| Dimension (L×W×H) | 166×166×110mm |
| Weight | 2kg |
The Insize 0435-HZ11 is an On-Line pH Meter designed for continuous water quality monitoring in demanding industrial environments, including chemical processing, oil refining, metallurgy, pharmaceuticals, power stations, and environmental protection. This versatile instrument simultaneously measures pH, ORP (Oxidation-Reduction Potential), and temperature, providing comprehensive water quality data in real-time. The meter features an included combination pH/ORP electrode with a PTFE double salt bridge junction and Ag/AgCl reference structure for stable, reliable measurements.
The HZ11 offers a pH range of 0.00~14.00pH with ±(0.05pH+1d) accuracy, an ORP range of -1800mV~+1800mV, and temperature measurement from -10.0°C~120.0°C. It features automatic slope calculation and temperature compensation (via a PT1000 unit), and automatically recognizes 4.00, 6.86, and 9.18 standard solutions for easy calibration. The meter includes power failure data protection, upper and lower limit alarms, and an isolated (4~20)mA DC output signal (maximum load 750Ω) for integration with control systems. It is designed for tray or wall mounting with a 140×140mm hole-opening size. The IP65-rated housing measures 166×166×110mm and weighs 2kg, operating on AC 220V, 50Hz.
Continuous Industrial Water Monitoring with the Insize 0435-HZ11 On-Line pH Meter
Monitor pH, ORP, and temperature continuously with the Insize 0435-HZ11 On-Line pH Meter. Engineered for industrial water quality monitoring in chemical, petrochemical, metallurgical, pharmaceutical, and power generation facilities, this robust instrument delivers reliable real-time data. Its included combination pH/ORP electrode features a PTFE double salt bridge and Ag/AgCl reference for stable performance, while the IP65-rated housing ensures durability in harsh environments.
Key Features and Benefits:
-
Multi-Parameter Measurement: Simultaneously measures pH (0.00~14.00), ORP (-1800mV~+1800mV), and temperature (-10.0°C~120.0°C).
-
High Accuracy: pH accuracy of ±(0.05pH+1d), ORP accuracy of ±(10mV+1d), and temperature accuracy of ±(1.0°C+1d).
-
Automatic Calibration: Automatically recognizes 4.00, 6.86, and 9.18 standard solutions with automatic slope calculation.
-
Temperature Compensation: Uses a PT1000 temperature compensation unit for accurate readings.
-
Reliable Output: Isolated (4~20)mA DC output signal with maximum load 750Ω.
-
Alarm Functions: User-settable upper and lower limit alarms for pH and ORP.
-
Power Failure Protection: Ensures data integrity during power interruptions.
-
Flexible Installation: Tray-mounted or wall-mounted design with a 140×140mm hole-opening size.
-
Durable Construction: IP65 protection level with PP housing and PTFE double salt bridge junction.
-
Industrial-Grade Electrode: Ø30×170mm combination electrode with 3/4NPT installation, ≤0.6MPa pressure range, suitable for routine or contaminated samples.
