S7-1202A Voltage Adjustable LOW POWER SWITCHING POWER SUPPLY
BDT 9,833/-
Product Details
.Output voltage: 2V, 4V, 6V, 8V, 10V, 12Vrms
.Output current: 2A
.Output frequency: 50Hz, 60Hz (line tracing)
.Output accuracy: Voltage: 1%, Frequency: 1%
.Input voltage: 85~265VAC 50/60Hz
.Dimensions: 110(W)×75(H)×140(D)mm
.Weight: 350g
| Output voltage: | 2V, 4V, 6V, 8V, 10V, 12Vrms |
| Output current: | 2A |
| Output frequency: | 50Hz, 60Hz (line tracing) |
| Output accuracy: | Voltage: 1%, Frequency: 1% |
| Input voltage: | 85~265VAC 50/60Hz |
| Dimensions: | 110(W)×75(H)×140(D)mm |
| Weight: | 350g |
.Output voltage: 2V, 4V, 6V, 8V, 10V, 12Vrms
.Output current: 2A
.Output frequency: 50Hz, 60Hz (line tracing)
.Output accuracy: Voltage: 1%, Frequency: 1%
.Input voltage: 85~265VAC 50/60Hz
.Dimensions: 110(W)×75(H)×140(D)mm
.Weight: 350g
S7‑1202A Voltage Adjustable Low Power Switching Power Supply
The S7‑1202A is a reliable and compact low power switching power supply designed for precision applications in laboratories, education, and testing environments. It offers selectable output voltages of 2V, 4V, 6V, 8V, 10V, and 12 Vrms with a stable output current of 2A, making it ideal for experiments and training setups that require consistent performance. With output frequency options of 50 Hz and 60 Hz (line tracing) and accuracy rated at 1% for both voltage and frequency, this unit ensures dependable results across a wide range of uses. Supporting a broad input voltage range of 85 to 265 VAC at 50/60 Hz, the S7‑1202A is suitable for global operation. Its compact design measures 110 × 75 × 140 mm and weighs only 350 g, making it easy to integrate into any workspace. Built for durability and efficiency, the S7‑1202A is the perfect choice for educators, engineers, and hobbyists seeking a versatile and portable power supply solution.
