LSP305 Digital DC Power Supply
BDT 13,495/-
Product Details
Brand: MCP
Model: LSP305
Country Of Origin: China
Features
-
Digital voltage and current adjustment
-
Voltage and current preset function
-
Four sets of preset voltage/current storage and recall function
-
CV/CC auto switching
-
4‑digit voltage and current LED display
-
Output off function & output locking function
-
Low ripple and noise
-
Over voltage protection (OVP), over current protection (OCP), over heat protection
Specifications
-
Load regulation: CV ≤ 0.01% + 3mV CC ≤ 0.1% + 10mA
-
Line regulation: CV ≤ 0.01% + 3mV CC ≤ 0.1% + 3mA
-
Ripple & noise (20Hz–20MHz): CV ≤ 2mVrms CC ≤ 3mArms
-
Voltage resolution: 10mV
-
Current resolution: 1mA
-
Display accuracy (25°C ±5°C): V ≤ ±(0.5% + 20mV) A ≤ ±(0.5% + 10mA)
-
Temperature coefficient: V ≤ 100ppm + 10mV A ≤ 100ppm + 5mA
-
Response time (10% rated load): Voltage rise ≤ 100ms, Voltage drop ≤ 100ms
-
Cooling method: Fan
-
Working temperature: 0–40°C; relative humidity ≤ 85% RH
-
Storage temperature: 0–60°C; relative humidity ≤ 85% RH
-
Dimensions (W×H×D): 100 × 165 × 265 mm
-
Working voltage: AC110V / 220V ±10%, 50Hz/60Hz
| Load regulation: | CV ≤ 0.01% + 3mV CC ≤ 0.1% + 10mA |
| Line regulation: | CV ≤ 0.01% + 3mV CC ≤ 0.1% + 3mA |
| Ripple & noise: | (20Hz–20MHz): CV ≤ 2mVrms CC ≤ 3mArms |
| Voltage resolution: | 10mV |
| Current resolution: | 1mA |
| Display accuracy: | (25°C ±5°C): V ≤ ±(0.5% + 20mV) A ≤ ±(0.5% + 10mA) |
| Temperature coefficient: | V ≤ 100ppm + 10mV A ≤ 100ppm + 5mA |
| Response time: | (10% rated load): Voltage rise ≤ 100ms, Voltage drop ≤ 100ms |
| Cooling method: | Fan |
| Working temperature: | 0–40°C; relative humidity ≤ 85% RH |
| Storage temperature: | 0–60°C; relative humidity ≤ 85% RH |
| Dimensions: | (W×H×D): 100 × 165 × 265 mm |
| Working voltage: | AC110V / 220V ±10%, 50Hz/60Hz |
Features
-
Digital voltage and current adjustment
-
Voltage and current preset function
-
Four sets of preset voltage/current storage and recall function
-
CV/CC auto switching
-
4‑digit voltage and current LED display
-
Output off function & output locking function
-
Low ripple and noise
-
Over voltage protection (OVP), over current protection (OCP), over heat protection
Specifications
-
Load regulation: CV ≤ 0.01% + 3mV CC ≤ 0.1% + 10mA
-
Line regulation: CV ≤ 0.01% + 3mV CC ≤ 0.1% + 3mA
-
Ripple & noise (20Hz–20MHz): CV ≤ 2mVrms CC ≤ 3mArms
-
Voltage resolution: 10mV
-
Current resolution: 1mA
-
Display accuracy (25°C ±5°C): V ≤ ±(0.5% + 20mV) A ≤ ±(0.5% + 10mA)
-
Temperature coefficient: V ≤ 100ppm + 10mV A ≤ 100ppm + 5mA
-
Response time (10% rated load): Voltage rise ≤ 100ms, Voltage drop ≤ 100ms
-
Cooling method: Fan
-
Working temperature: 0–40°C; relative humidity ≤ 85% RH
-
Storage temperature: 0–60°C; relative humidity ≤ 85% RH
-
Dimensions (W×H×D): 100 × 165 × 265 mm
-
Working voltage: AC110V / 220V ±10%, 50Hz/60Hz
The LSP Series Digital DC Power Supply is a precision laboratory and industrial testing solution designed for stable and accurate performance. With digital voltage/current adjustment, four preset storage and recall functions, and CV/CC auto switching, it offers flexibility and reliability for engineers and researchers. The 4‑digit LED display ensures clear monitoring, while built‑in protections (OVP, OCP, OHP) safeguard equipment during operation. Compact and fan‑cooled, the LSP Series delivers low ripple and noise output, making it ideal for sensitive electronics testing and long‑term laboratory use.
