19-PIECE JIG SET
BDT 0/-
Product Details
Brand: INSIZE
Model: ISY-500
Country Of Origin: China
Features:
Comprehensive 19-piece modular setup
Ø6mm anvils for enhanced holding stability
Adjustable spring anvil with a 0-40mm range
Secure clamping with included handles
Highly versatile modular components for custom setups
Designed for repeatable CMM inspection accuracy
Can be customized for specific applications
| Anvil Diameter: | Ø6mm |
| Adjustable Anvil Range: | 0-40mm |
| Anvil Stroke: | 24mm |
| Base Plate Size: | 300×240×20mm |
| Block Size: | 120×90×20mm |
The INSIZE ISY-500 CMM Jig Set is a comprehensive, 19-piece modular fixturing system designed to securely hold complex workpieces during Coordinate Measuring Machine (CMM) inspection. Featuring a larger Ø6mm anvil compared to standard models, this set provides enhanced stability for larger or heavier parts.
The kit is highly versatile, featuring a standard spring anvil, an adjustable spring anvil (with a 0-40mm range), two large base plates, ten modular blocks, connecting plates, and clamp handles. This modular design allows metrology professionals to build custom holding setups for virtually any workpiece geometry, ensuring repeatable and accurate measurements. The system is marked as customizable, making it adaptable to specific industrial requirements.
INSIZE ISY-500 CMM Jig Set – 19-Piece Modular Fixture System with Ø6mm Anvils
Ensure absolute stability and repeatability during your dimensional inspections with the INSIZE ISY-500 CMM Jig Set. Designed for metrology labs and quality control departments, this comprehensive 19-piece modular fixture system provides everything needed to securely hold complex workpieces on a Coordinate Measuring Machine (CMM).
Key Features & Benefits:
-
Enhanced Holding Power: Features a specialized Ø6mm anvil design, offering robust support for larger or irregularly shaped parts.
-
Complete Modular Kit: Includes 1x Spring Anvil (ISY-500-1), 1x Adjustable Spring Anvil (ISY-500-2), 2x Base Plates (ISY-500-3), 10x Blocks (ISY-500-4), 2x Connecting Plates (ISY-500-5), 1x Connecting Block (ISY-500-6), and 2x Clamp Handles (ISY-500-7).
-
Adjustable Spring Anvil: The ISY-500-2 component allows for precise adjustments with a 0-40mm range and a 24mm anvil stroke, making it incredibly versatile.
-
Sturdy Construction: Built with durable materials to withstand the rigors of daily inspection use. The large 300x240x20mm base plates provide a solid foundation for any assembly.
-
Customizable Configuration: The modular nature of the connecting plates and blocks allows you to build custom fixtures tailored to specific workpiece geometries.
-
Customizable to Your Needs: Marked as "Can be customized," this system can be tailored to meet specific industry or part requirements.
